The ultimate boom

The ultimate boom

The 6-section 60m rounded boom is made of high tensile steel, which allows for decreased boom weight and increased boom strength.

Control of asymmetric extension width of outriggers

Control of asymmetric extension width of outriggers

When operating the crane with the asymmetric outriggers extended, the AML automatically detects the extension width of outriggers at the front and rear, and to the left and right of the crane to allow maximum work capacity in each area. When slewing the boom from the longer outrigger area to the shorter outrigger area, the AML automatically detects the motion and displays the maximum capacity depending on each of the extension widths of outriggers, and brings the motion to a slow stop before it reaches the limits of the allowed capacity. Therefore, even in the case of operator error, the AML's slow stop function will help to minimize any safety risk.

Lift Adjuster

Lift Adjuster

Boom deflection occurs when the winch is wound due to the weight of the lifted load, causing the lifted load to sway in a direction that expands the load radius as it clears the ground. This situation requires very careful and precise operation to mitigate outward movement of the hook block. In the lift adjuster function, the AML detects boom deflection and automatically adjusts boom angle to mitigate outward hook block movement.

Crane

Max. Lifting Capacity Boom 180t x 2.7m
Max. Lifting Height Boom 61.5m
Boom+Jib 99.0m
Max. Load Radius Boom 56.0m
Boom+Jib 76.0m
Boom Length 13.2m - 60.0m

Carrier

Engine Model Mercedes Benz (EU Stage Ⅲ B)
Max. Output Carrier 405 kW (551 HP)
Superstructure 129 kW (175 HP)
Max Traveling Speed 85km/h
Drive/Steering 10 x 8 x 10
Overall Length 15,126mm
Overall Width 3,000mm
Overall Height 3,990mm
