AT-146TE-4
Standard model for electric wire work. AT-146TE is equipped with the insulated boom and optical fiber cable as standard for safety operation.
Compare products
Product Specs
- Bucket Inside Dimensions 1.1m × 0.74m × 0.9m
- Bucket Swing (Slewing) Angle 240°(Left 120°- Right 120°)
- Elevation -16° – 80°
- Material of Bucket F.R.P.
- Max. Bucket Bottom Height 14.5m + 0.6m
- Max. Bucket Loading Capacity 250 kg
- Max. Main Boom Length 12.59m
- Outrigger Bases 4.1m
- Type of boom Telescopic
Product description
High operating efficiency and excellent safety.
AT-146TE offers the maximum 14.5m +0.6m bucket bottom height. This model can be mounted on light duty trucks. U specification has the bucket with Up/Down function, the up/down stroke and compact bucket frame enable optimal positioning to support efficient work. Automatic stowing of the boom is equipped as standard feature. The function reduces the time needed for stowing. The working range is automatically controlled by detecting the loading status and the outrigger position by Automatic motion and moment controller (AMC).
