AT-270TG-2
AT-270TG offers consistent performance with telescopic boom and 27.0m height bucket. It enables comfortable operation in high and wide areas in the class.
Compare products
Product Specs
- Bucket Inside Dimensions 0.7m × 1.2m × 0.9m
- Bucket Swing (Slewing) Angle 200°
- Elevation -12° – 80°
- Material of Bucket Steel or F.R.P
- Max. Bucket Bottom Height 27.0m
- Max. Bucket Loading Capacity 200kg
- Max. Main Boom Length 25.52m
- Outrigger Bases 4.4m
- Type of boom Telescopic
Product description
Fully equipped to support safe, comfortable operation
AT-270TG offers the maximum 27.0m bucket bottom height with telescopic boom. This model can be mounted on medium duty trucks. Straight line movement in any direction is achieved through integrated control of boom telescoping, elevating, slewing, and bucket swing. A full range of equipment to support safe and comfortable work, including bucket swing, boom automatic stowing system, elevating and slewing speed control system. The AMC (Automatic Motion and Moment Controller) automatically controls the work range by detecting the loading status and the outrigger position.
