GT-600ER-3
Designed and built completely by Tadano, the GT-600ER-3 delivers powerful lifting performance and enhanced mobility with a 60,000 kg capacity, right-hand-drive configuration, and a full-width cab engineered for demanding roads and job sites.
Compare products
Product Specs
- BRAND Tadano
- Capacity 60 t
- Dimensions L: 13.14 m W: 2.80 m H: 3.78 m
- Engine Daimler OM457LA
- GVM 39,680 kg
- Main Boom Length 11.0 m – 43.0 m
- Max. Crane Capacity 60 t
- Max. Load Moment 60 t x 2.7m
- Max. Radius 44.0 m
Product description
High-Performance, Road-Ready 60,000 kg Class Truck Crane
The GT-600ER-3 truck crane is engineered by Tadano to exceed rigorous road requirements while offering outstanding mobility and stability. With a 60-ton capacity, it features a 42.0 m / 137.8 ft rounded boom, plus a two-stage jib of 10.1 m / 33.1 ft to 17.7 m / 58.1 ft with selectable offsets. Maximum lifting height reaches 42 m / 137.8 ft with the boom and up to 59.3 m / 194.5 ft with the jib. The right-hand-drive carrier incorporates a full-width cab, a Daimler OM470 EURO3 engine, and ZF TraXon AMT for efficient, smooth travel, supported by leaf-spring front suspension and Hendrickson ULTIMAAX rear suspension. Safety and precision are strengthened by the Tadano Automatic Moment Limiter (AML-C), Smart Chart, and optional HELLO-NET telematics.
