Aerial Work Platforms
AT-300CG-2
Aerial Work Platforms
AT-300CG-2
Brochure
- Specification
General Purpose Use (Telescopic)
| Max. Basket Loading Capacity | 250kg | |
|---|---|---|
| Material of Basket | Steel | |
| Max. Basket Bottom Height | 30.4m | |
| Max. Basket Bottom Depth | 7.5m | |
| Basket Swing (Slewing) Angle | 313°(Left93°- Right 220°) | |
| Basket Inside Dimensions | 0.7m × 1.5m × 0.95m | |
| Boom Length | Min. Retracted | 9.0m + 5.2m |
| Max. Extended | 22.2m + 7.6m | |
| Elevation | -12° - 80° | |
| Type of boom | Telescopic & Articulating | |
| Extension width of outriggers | Max. | 4.66m |
