Tadano’s AML-C is easy to use. It allows the operator to simultaneously monitor: boom angle, boom length, operating pressure of elevating cylinder, the extended width of the outriggers, slewing position, rated lifting capacity and present hook weight. All of this enables the AML-C to move easily through lifting capacity changes without changing configurations and codes to make a lift.
Telescopic Boom Crawler Cranes
Load moment indicator (AML-C)
Optimized lifting performance for reduced width configurations. Reduced width, asymmetric track setup can give significant capacity improvements when compared to symmetrical track width settings.
3D Lift Plan*
Customize 3D lift simulation at your fingertips for FREE**. Easy access and user friendly webpage allows you to calculate crane configurations and ground bearing pressure simultaneously. Moreover, you can print out detailed configurations and 3D graphics to further support your work preparation.
*3D Lift Plan is a product of A1A Software LLC. **Advanced customize functions will be extra.
Hello-Net is a standard feature used to support our customers’ efficient crane operations straight from your computer or mobile device. The customer can monitor their crane activity, work history, machine position data, and maintenance information. Tadano offers advanced customer support with the Hello-Net system.
|Crane Capacity||Boom||35t x 3.0m|
|Max. Lifting Height||Boom+Jib||33.4m / 38.9m|
|Boom Length||10.9 m - 27.2 m|
|Jib Length||7.2 m / 12.8 m|
|Engine Model||Cummins QSB4.5|
|Max. Traveling Speed||1.9km/h(Low)3.1km/h(High)|
|Overall Width (Tracks Extended)||4.8m|
|Overall Width (Tracks Retracted)||3.0m|
|Overall Width (Tracks Removed)||2.8m|
