Telescopic Boom Crawler Cranes
GTC-550 (Preliminary)
Telescopic Boom Crawler Cranes
GTC-550 (Preliminary)
Brochure
Spec Sheet
- Specification
Crane
| Crane Capacity | Boom | 50 t x 2.5m |
|---|---|---|
| Max. Lifting Height | Boom+Jib | 41.9m |
| Boom Length | 11.0m - 34.7m | |
| Jib Length | 8.8m / 15.2m | |
Carrier
| Engine Model | Cummins QSB6.7 | |
|---|---|---|
| Tier4f(EUROMOT4) | 194kW/2,200min-1 | |
| Max. Traveling Speed | 1.9km/h(Low)3.1km/h(High) | |
| Overall Length | 13.2m | |
| Overall Width (Tracks Extended) | 5.2m | |
| Overall Width (Tracks Retracted) | 3.48m | |
| Overall Width (Tracks Removed) | 2.96m | |
| Overall Height | Transport Configlation | 3.69m |
