PM 12.5 S
The PM 12.5 S combines high lifting capacity, precision movements, and excellent maneuverability—ideal for demanding medium-duty lifting applications.
Series Specs
| PM 12521 SP | PM 12522 SP | PM 12523 SP | PM 12523 SP + J252 | PM 12524 SP | PM 12524 SP + J252 | PM 12525 SP | |
|---|---|---|---|---|---|---|---|
| Spec Sheet |  | | | | | | |
| Spec Sheet | | | | | | | |
Product description
Precision in motion.
The Tadano PM 12.5 S Series offers the perfect balance of strength and agility. Its double connecting rod system ensures smooth, constant, and precise boom movements, while the hydraulic moment limiting device guarantees safe operation.
Available in multiple configurations, the series delivers lifting moments of 10.4 to 11.4 tonne-meters with horizontal outreaches from 8.1 up to 14.95 meters and vertical outreaches from 11.5 up to 18.25 meters. With jib options, outreach extends to 17.9 meters horizontally and 20.8 meters vertically.
Available in multiple configurations, the series delivers lifting moments of 75.3 to 82.5 ton-feet with horizontal outreaches from 26.6 up to 49.0 feet and vertical outreaches from 37.7 up to 59.9 feet. With jib options, outreach extends to 58.7 feet horizontally and 68.2 feet vertically.
As part of the Silver line, the PM 12.5 S Series features a manual control valve block as standard, with multifunction radio control available as an option. Designed for reliability, safety, and performance, it is a versatile crane for a wide variety of jobs.
Vehicle Type
-
3.50 ton
7.71 lbs
-
5.00 ton
11.02 lbs
-
6.00 ton
13.22 lbs
-
6.50 ton
14.33 lbs
-
7.50 ton
16.53 lbs
-
8.00 ton
17.63 lbs
-
10.00 ton
22.04 lbs
-
12.00 ton
26.45 lbs
-
13.50 ton
29.76 lbs
-
15.00 ton
33.06 lbs
-
18.00 ton
39.68 lbs
-
19.00 ton
41.88 lbs
-
26.00 ton
57.32 lbs
-
32.00 ton
70.54 lbs
-
44.00 ton
97.00 lbs
- 2 Stabilizers STANDARD
- 2 Stabilizers XL
- 4 Stabilizers
