Feb. 7, 2022

Introducing New 16 Metric tons Capacity Rough Terrain Crane "GR-160N" for Japanese Domestic Market

Pursuing environmental friendliness and work performance, with strengthened commitments to DX, a growing need

Tadano Ltd. (Head office: Takamatsu city, Kagawa prefecture; President: Toshiaki Ujiie) will launch the new rough terrain crane, "GR-160N CREVO160 G5" with a maximum lifting capacity of 16 metric tons for Japanese domestic market on February 7, 2022 (Monday).

【Product details page】https://www.tadano.co.jp/products/rc/gr-160n-5/index.html (Japanese)


*Rough Terrain Crane
The rough terrain crane is a self-propelled crane that can travel and be operated from a single driver's seat. It is one of the most popular cranes in urban construction projects because of its excellent mobility in narrow spaces, compactness, and small turning radius.

*CREVO
The CREVO is a word coined from CRANE and EVOLUTION. This is the fifth generation of the CREVO series since its development in 1995. The CREVO160 G5 follows the CREVO250 G5 that was released in September of last year, and is the second entry in the G5 Series.



Development Concept

This model retains the compact body size of the earlier model, while extending the maximum length of the boom by 50 cm to 28.0 m. New functions during crane operation have reduced CO2 emissions and fuel consumption, and a diesel engine which complies with EU Stage V emission standards has been adopted. In addition, visibility while traveling and operating has been improved, delivering comfortable and safe operations.
As the digital shift in the construction and building industry progresses, Tadano is also working to strengthen its digital data and digital services in order to provide "Lifting Solution" that goes beyond "Lifting Equipment".

Features

- Retaining a compact body while improving the efficiency of high lift work
This model retains the same vehicle dimensions and weight as the earlier model while extending the maximum boom length by 50 cm to 28.0 m. In combination with the 6.9 m power tilt jib, this helps improve the efficiency of high lift work.

- Environmental considerations and operational efficiency improvement
New functions, which are aimed at improving operational efficiency and considering the environment, include "automatic acceleration"*1 that controls engine speed according to the amount of crane lever operation, and "automatic pump stop"*2 that stops the PTO pump when the crane is not being operated in order to reduce CO2 emissions and fuel consumption. At the same time, a new-generation diesel engine which complies with EU Stage V emission standards has been adopted.
*1:The engine speed is controlled automatically and is linked with the amount of lever/pedal operation when the crane is being operated. This makes it possible to adjust the speed of crane work using only the lever, without operating the accelerator pedal. In addition, because the engine speed increases more efficiently compared to constantly depressing the accelerator pedal, fuel consumption and engine noise are also reduced.
*2: When the automatic pump stop switch is turned ON and the crane is not used for a certain period of time, the PTO pump is automatically turned OFF, reducing fuel consumption.


- Tadano View System with improved visibility
Improvements have been made to the Tadano View System that supports safe driving and operation. A new rear left view camera, slewing table rear view camera, and slewing table rear left view camera have been added, for a total of five cameras as standard equipment. Up to three patterns for the camera selections on the large-size display can be registered, providing support for checking safety in the surrounding area.
The "human alert system" that detects and warns the driver when people are present has also been improved for a better detection rate, improving visibility and safety while driving.


- High-performance operation space
The crane operating information and various operation setting functions are concentrated on a large 12.1-inch color touchscreen panel. The LCD panel uses materials that prevent scatter reflection and condensation, and are resistant to impact. Because the touchscreen panel is an electrostatic capacitance type, it can be operated in a way that feels similar to a smartphone.
Improvements to the electrical operating system also produce operability with an all-new feeling of a perfect fit. In addition to previous speed adjustments, Feeling Operation allows precise control adjustments that match the operator's perception. More advanced sensitivity adjustment has also been adopted.


- Setup radio controller (option)
"Setup radio controller" has been fully renovated to allow safe and efficient work preparation and machine retracting while checking the surrounding conditions. A large 2.7-inch reflection-type color screen ensures high visibility even outdoors on a sunny day. The hand-held radio controller can be operated to extend and retract outrigger beams and jacks, stow booms (hook-in), and mount and stow jibs.
* The operations that can be performed by Setup radio controller are only work preparation and machine retracting work. Radio controller cannot be used for crane operation.


- Provision of digital data and digital services
Tadano is also focusing on the provision of digital data and digital services that include "Lift API", "BIM models", "Hello-Net" telematics web information service, and "Hello-Data Link" smartphone app, aiming to provide support for safe, high-quality, and efficient lifting work.

Overview

Product name: GR-160N [CREVO160 G5]
Model name: GR-160N-5

Main Specifications

Crane Model GR-160N-5
Crane Capacity 16 metric tons × 3.0m (Boom)
3.2 metric tons (Single top)
Max. Lifting Height Boom 28.9m
Jib 35.8m
Max. Working Radius Boom 24.5m
Jib 28.0m
Boom Length 6.5m - 28.0m
Jib Length 4.5m, 6.9m
Carrier Model TADANO YDS-T018
Engine Model Cummins QSB6.7-4E
Engine Max. Output For traveling: 179kW{243PS}/2,200min‐1{rpm}
For operating: 149kW{202PS}/1,500min-1{rpm}
Engine Max. Torque 949N·m {96.8 kgf·m}/1,500min-1{rpm}
Overall Length 8,310mm
Overall Width 2,200mm
Overall Height 3,150mm
GVW 19,795kg

Tadano Ltd. Introduction

Tadano Ltd. developed Japan's first hydraulic truck crane in 1955, and has led the industry as a leading company in construction cranes. We are always striving to develop products that meet the needs of the times and aim to become the world's number one in the LE (Lifting Equipment) business. With the acquisition of Faun GmbH in 1990 and the Demag brand crane business in 2019, we are committed to further globalization.
By developing products and conducting business activities that contribute to the development of local and international communities and help preserve the global environment, we aim to meet the expectations of all our stakeholders and become a company that pursues "Further Excellence for the World and the Future".

[Corporate profile]
Corporate Name: Tadano Ltd.
Head Office: Ko-34 Shinden-cho, Takamatsu, Kagawa, 761-0185, Japan
Representative: President and CEO Toshiaki Ujiie
Established: August 24, 1948
URL:https://www.tadano.com/
Business areas: Production and sale of products including construction cranes, truck loader cranes, and aerial work platforms

[Contact for inquiries regarding this release]
Marketing Dept., Tadano Ltd.
e-mail:marketing.communications@tadano.com
