Aerial Work Platforms
AT-146TE-4
Aerial Work Platforms
AT-146TE-4
Brochure
- Specification
General Purpose Use (Telescopic)
| Max. Basket Loading Capacity | 250kg | |
|---|---|---|
| Material of Basket | F.R.P | |
| Max. Basket Bottom Height | 14.5m + 0.6m | |
| Basket Swing (Slewing) Angle | 240°(Left120°- Right 120°) | |
| Basket Inside Dimensions | 1.1m × 0.74m × 0.9m | |
| Boom Length | 5.09m - 12.59m | |
| Elevation | -16° - 80° | |
| Type of boom | Telescopic | |
| Extension width of outriggers | Max. | 4.1m |
