Truck Loader Cranes
TM-ZX1500 series
Truck Loader Cranes
TM-ZX1500 series
Brochure
Brochure
Spec Sheet
- Specification
Crane
| TM-ZX1505 | |||
|---|---|---|---|
| Crane Capacity | 15,000kg x 2.0m | ||
| Section | 5 | ||
| Max. Lifting Height (Approx.) | 20.0m | ||
| Max. Load Radius | 18.07m | ||
| Boom Length | 5.3m - 18.5m | ||
| Slewing | Continuous 360° | ||
| Extension width of outriggers | Max. | 5.8m | |
| Mid. | 4.0m | ||
| Min. | 2.26m | ||
| Remarks | availability of TM-ZX1505HRS depends on countries | ||
